Suncoast Audio Direct

Luxsin X9 Flagship Headphone DAC/AMP

$1,099.00

Description

The Luxsin represents the pinnacle of portable audio engineering, combining cutting-edge DAC technology with intelligent tuning algorithms. Its AK4499EX chipset paired with OPA1612 op-amps delivers exceptional clarity with -120dB THD+N and 128dB dynamic range. The proprietary HP-EQ system analyzes over 2500 headphone profiles in real-time, automatically compensating frequency response to match your preferred target curve. Precision R2R volume circuitry maintains 0.1dB channel accuracy, while impedance auto-detection optimizes gain settings for any headphone. The 4.0" 1080P touchscreen provides intuitive control with customizable VU metering and blackout mode. Advanced features including digital crossfeed, adjustable soundstage parameters, and full-balanced architecture throughout ensure fatigue-free listening with exceptional transparency. The CNC-machined aluminum design with ergonomic 15° incline completes a device engineered for discerning audiophiles who demand both sonic excellence and refined aesthetics.

*Loyalty power perk rewards terms and conditions

technical Specifications

Play & DAС
support DSD512, PCM 768KHz 32-bit
Bluetooth audio input
BT5.0, support AAC/SBC
USB-B audio input
support Windows (10, 11), Android,
IOS. support DSD512, PCM 768KHz 32-
bit
Optical/Coaxial audio input
support PCM 192KHz 24-bit, DoP64
HDMI ARC
support PCM 192KHz 24-bit
Analog input
RCA (unbalance), max gain +10dB
Analog audio output interfacе
XLR (balanced)+RCA
(unbalanced)+subwoofer output
XLR Audio Output
output level 4.2Vrms@0dBFS
Frequency Response: 20Hz-20KHz
(±0.25dB)
Dynamic Range: > 128dB
Signal-to-Noise Ratio (SNR): 128dB
THD+N: <0.000096% (-120.3dB) @
Unweighted
Crosstalk: >-117dB
RCA Audio Output
output level 2.1Vrms@0dBFS
Frequency Response: 20Hz~20KHz
(±0.25dB)
Dynamic Range: > 125dB
Signal-to-Noise Ratio (SNR): 125dB
THD+N: <0.00010% (-119dB)@
Unweighted
Crosstalk: >-114dB
Headphone Audio Output
output level 4-15Vrms@0dBFS
Frequency Response: 20Hz~20KHz
(+0.25dB)
Dynamic Range: >> 128dB
Signal-to-Noise Ratio (SNR): >128dB
THD+N: <0.00016% (-116dB) @
Unweighted

Model
X9
Display
4-inch TFT Fully Laminated
Touchscreen (960X400)
Hardware solution
DAC: AK4191EQ+AK4499EX USB: XMOS
XU316; Bluetooth decoding: QCC5125
Audio processor
AKM 7739 DSP
Op-Amp chip
OPA1612
dimension Color
Width: 300mm* Length: 206mm* Silver
Height: 65mm Weight
Power supply
Ultra-Low Noise Linear Power Supply
Rated Power
25W
Packing list
Power Cable x1, Remote Controller х1,
USB-B Cablex1, Type-C OTG Cablex1,
User Manual x)
3.72kg
Operation method
Touchscreen, Infrared + Bluetooth
Remote Control, Luxsin App
(compatible with Android and iOS)
