Number of Headphone Channels
Single Channel
Recommended Headphone Impedance
Not Specified by Manufacturer
Headphone Output Power
4.4 mm Balanced:
385 mW into 600 Ohms
1890 mW into 64 Ohms
1200 mW into 32 Ohms
1/4" Unbalanced:
98 mW into 600 Ohms
870 mW into 64 Ohms
1600 mW into 32 Ohms
Show Less
Analog Audio I/O
1x 4.4 mm TRRRS Balanced Input (Rear Panel)
1x 1/8" / 3.5 mm TRS Unbalanced Input (Rear Panel)
1x Stereo RCA TS Unbalanced Stereo Line Input (1 Stereo Pair, Rear Panel)
1x 4.4 mm TRRRS Balanced Stereo Line Output (Rear Panel)
1x 1/4" TRS Unbalanced Stereo Headphone Output (Front Panel)
1x 4.4 mm TRRRS Balanced Stereo Headphone Output (Front Panel)
Show Less
Digital Audio I/O
No
USB I/O
No
Wireless
No
Frequency Response
10 Hz to 200 kHz ±3 dB
Power Requirements
AC/DC Power Adapter (Included)
Number of Headphone Channels
Single Channel
Recommended Headphone Impedance
Not Specified by Manufacturer
Headphone Output Power
4.4 mm Balanced:
385 mW into 600 Ohms
1890 mW into 64 Ohms
1200 mW into 32 Ohms
1/4" Unbalanced:
98 mW into 600 Ohms
870 mW into 64 Ohms
1600 mW into 32 Ohms
Headphone Output Current
2600 mA
Digital Chipset
Not Specified by Manufacturer
Analog Circuitry
Transistor:
MOSFET
EQ
No
Display
No
Connectivity
Analog Audio I/O
1x 4.4 mm TRRRS Balanced Input (Rear Panel)
1x 1/8" / 3.5 mm TRS Unbalanced Input (Rear Panel)
1x Stereo RCA TS Unbalanced Stereo Line Input (1 Stereo Pair, Rear Panel)
1x 4.4 mm TRRRS Balanced Stereo Line Output (Rear Panel)
1x 1/4" TRS Unbalanced Stereo Headphone Output (Front Panel)
1x 4.4 mm TRRRS Balanced Stereo Headphone Output (Front Panel)
Digital Audio I/O
No
USB I/O
No
Wireless
No
Performance
Frequency Response
10 Hz to 200 kHz ±3 dB
Gain/Trim Range
0 dB to 18 dB (in 6 dB Steps)
Maximum Input Level
4.4 mm Inputs:
7.4 Vrms
RCA Inputs:
3.8 Vrms
1/8" / 3.5 mm Inputs:
1.92 Vrms
Impedance
Line Outputs:
< 200 Ohms (Balanced)
< 100 Ohms (Unbalanced)
Headphone Outputs:
< 1 Ohms (Balanced, Unbalanced)
THD+N
Line Inputs:
0.006% (Balanced, A-Weighted)
0.005% (A-Weighted)
Line Outputs:
< 0.007% (Balanced, 0 dBFS)
< 0.015% (Unbalanced, 0 dBFS)
Headphone Outputs:
< 0.005% (1V at 16 Ohms)
SNR
4.4 mm Line Inputs:
> 121 dBA (at 15.2V)
1/8" / 3.5 mm Line Inputs:
> 120 dBA (at 7.6V)
4.4 mm Line Outputs:
< 110 dBA (at 0 dBFS)
4.4 mm Balanced Headphone Outputs:
< 116 dBA (at 0 dBFS)
1/4" Headphone Outputs:
< 115 dBA (at 0 dBFS)
Mobile App Compatible
No
Mobile Device Compatibility
No
Power
Power Requirements
AC/DC Power Adapter (Included)
Ground Lift
No
AC/DC Power Adapter
5 VDC (Included)
Power Consumption
5 W (Standby)
12 W (Maximum)
Physical
Dimensions
6.2 x 4.6 x 1.4" / 15.7 x 11.7 x 3.6 cm
Weight
1.2 lb / 0.5 kg
