Deck section
Tracking system 4-track, 2-channel Stereo
Head configuration
REC/PLAY head one each for TAPE1 and TAPE2
ERASE head one each for TAPE1 and TAPE2
Tape speed 4.8cm/sec.
Pitch control ±12% (TAPE1 PLAYBACK only)
Fast rewinding time approximately 120 seconds (C-60 tape)
Wow and flutter 0.25% (W.RMS)
Frequency response
Chrome tape (Type II) 30 to 15k Hz（±4dB）
Normal tape (Type I) 30 to 13k Hz（±4dB）
Total S/N ratio 59dB (at max recording level input, A-weight)
Input/Output
Analog audio input
Connectors RCA × 1 pair
Nominal input level 0.28V
Input impedance 33k ohms
Mic input
Connector Standard 6.3mm (1/4") stereo jack
Nominal input level 0.38mV
Input impedance 3k ohms or more
Analogue audio output
Connector RCA × 1 pair
Nominal output level 0.46V
Output impedance 1k ohms
Headphone output
Connector Standard 6.3mm (1/4") stereo jack
Output power 15mW (at 32 ohms loaded)
USB digital output
Connector USB Type-B
Protocol USB2.0 FULL SPEED
Sampling frequency 8k / 11.025k / 16k / 22.05k / 32k / 44.1k / 48k Hz
Bit-depth 8 / 16bit
General
Operating power
AC 120V, 60Hz
AC 230V 50Hz
Power consumption 22W
Dimensions 17.1"(W) × 5.7"(H) × 11.3"(D) /
435(W) × 145(H) × 285.8(D)mm
Weight
US / Canada 9.3lbs. / 4.2kg
UK / Europe 10.2lbs. / 4.6kg
Accessories Remote control (RC-1331), AA batteries × 2, RCA audio cable, Owner's Manual (including Warranty)
