Advance Paris X-i75 Integrated Amplifier

Output power 8Ω
2 x 75W RMS

Output power 4Ω
2 x 110W RMS

Bandwidth
(-3dB) 10Hz-35kHz

Tone
+/- 10 dB

Distortion
<0.1%

Signal to noise ratio
> 90 dB

Channel separation
> 70 dB

Impedance d'entrée
47KΩ

Phono input impedance
47KΩ

Lvl. amplifier input
< 300mV

Phono MM/MC input level
2,5mV

Mains voltage
115-230V

consumption max.
300w

Transformer
1

Height
120 mm

Width
430 mm

Depth
320 mm

Net weight
8,6 Kg

CD input
1

Tuner input
1

Auxiliary Input
4

RCA Analog Input
1

Record output
1

Output for Subwoofer
1

Amp-Preamp
Preamp Output

Optical input
1

USB-A input
1

USB-B input
1

Output Pair of speakers
1

5 Volt Output WTX 500
1

Settings
Treble, Balance, Bypass, Hi Bias Switch, Bass, Volume
