Model
EverSolo DAC-Z8
Display Screen
3-inch LCD Screen
Chassis
Aviation aluminum alloy
DAC
ES 9038Pro
Audio Processor
XMOS XU316
OPA Chip
OPA1612*10
Power Supply
Low noise switching power supply
Bluetooth Audio Input
Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC
Bluetooth protocol
USB-B DAC Input
Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit and MQA
USB-C DAC Input
Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit, MQA
Optical Audio Input
Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Coaxial Audio Input
Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Analog Audio Output
Preamp output: XLR (balanced), RCA;
Headphone amp output: 6.35mm single-ended
USB Port
USB2.0*1（only for firmware upgrade）
Control Methods
Remote control, mobile APP control and knob control
Headphone Impedance
16-300Ω （low gain mode:16-32Ω/high gain mode: 32-300Ω）
XLR Audio Characteristics
Output level(Vrms): 4.1Vrms@0dBFS
THD+N@A-wt: 0.000062%@1kHz（-124dB@1kHz）
THD+N@No-wt：0.000069%@1kHz（-123dB@1kHz）
Noise@No-wt: <1.2uVrms
SNR @No-wt: 133dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -130dB@1kHz
DNR @No-wt: 133dB@1kHz
RCA Audio Characteristics
Output level (Vrms): 2.3Vrms@0dBFS
THD+N@A-wt: 0.000086%@1kHz(-121dB@1kHz)
THD+)@No-wt: 0.000097%@1kHz(-120dB@1kHz)
Noise @No-wt: <1.5uVrms
SNR @No-wt: 126dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -123dB@1kHz
DNR@No-wt: 126dB@1kHz
Headphone
(low gain mode)
Output level(Vrms): 1.2Vrms@0dBFS
Maximum undistorted power: 45 mW@32Ω
THD+N@A-wt: 0.00015%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00018%@1kHz(-115dB@1kHz)
Noise @No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
DNR @No-wt: 119dB@1kHz
Headphone
(high gain mode)
Output level(Vrms): 2.8Vrms@0dBFS
Maximum undistorted power: 26 mW@300Ω
THD+N@A-wt: 0.00016%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00016%@1kHz(-116dB@1kHz)
Noise@No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response): 20Hz-20kHz(±0.1dB)
DNR @No-wt: 124dB@1kHz
Power Input
AC 110~240V 50/60Hz
Rated Power
9W
Dimensions
270mm(W) * 187mm(D)* 50mm(H)
Packing List
Remote control*1, power cable*1, USB cable*1, product manual*1
