Chipset: SC6137D + CS43131 + TPA6120
Max Sampling Rate
- CD: PCM 16bit / 96kHz
- USB (USB flash drives): PCM 16bit / 96kHz
Headphone Impedance: 16–300Ω
Input: USB-A (USB flash drives), CD
Output: 3.5mm Headphones Jack, LINE, OPT, 12V Trigger
CD Formats: CDDA, CD-R / CD-RW (partially readable). Original pressed discs are recommended
CD-R Formats: FLAC / WAV / WMA / AAC / MP3
SACD Playback: Only SACDs with a CD layer are supported
Formats for USB Drive Playback: MP3 / WAV / FLAC / AAC / APE / WMA
IR Remote Control: Supports a maximum operating distance of up to 7 meters
Input Voltage: DC 5V / 2A
Firmware Upgrade: Firmware can be updated online via a USB-A port using a USB flash drive
3.5mm Output Performance (CD)
Rated Output Power: L+R ≥ 210mW + 210mW (32Ω / THD+N < 1%)
SNR: 121 dB (A-weighted)
THD+N: 0.002% (A-weighted)
Dynamic Range: 121 dB
Noise Floor: ≤ 3µV (A-weighted)
LINE Output Performance (CD)
Output Level: ≥ 2Vrms
SNR: 124 dB (A-weighted)
THD+N: 0.0009% (A-weighted)
Dynamic Range: 124 dB
Noise Floor: ≤ 3µV (A-weighted)
