Hardware
Processor
64-Bit, Quad-Core Arm Cortex
Sample Rate
PCM: Up to 384 kHz via Wi-Fi or Ethernet
DSD: Up to 11.2 MHz (DSD256)
Bit Depth
Up to 32 Bit
Connectivity
Wi-Fi
Dual-Band Wi-Fi 5 802.11a/b/g/n/ac
AirPlay
Yes
DLNA
Yes
Outputs
1 x Digital Coaxial RCA
Other Connectors
1 x USB Type-A 3.1 Gen 1 Input (from Storage)
1 x USB Type-A 3.1 Gen 1 Output (to DAC)
1 x Ethernet LAN
1 x Wi-Fi Antenna Terminal
1 x USB Type-C (Firmware Updates)
Formats Supported
PCM384
DSD256
MQA (Passthrough)
Physical Specifications
Power Requirements
9 VDC, 1.8 A to 15 VDC, 0.8 A
100 to 240 VAC, 50/60 Hz
Power Consumption
Maximum: 10 W
No Signal: 6 W
Dimensions
6.2 x 1.4 x 3.9" / 158 x 35 x 100 mm
Weight
1.14 lb / 578 g
